RA Series Lead-Acid Batteries

Capacity range: 33Ah-260Ah (C10, 25℃)
Rated voltage: 6V/12V
Designed floating charge life: 12 years
Meet IEC, JIS, GB/T and YD/T testing standards
Pass UL, CE, TLC, ISO9001, ISO14001 and ISO45001 certifications

Learn More

Get a Free Quote

Our Features

Features of RA Series Lead-Acid Batteries

Capacity range: 33Ah-260Ah (C10, 25℃)

Rated voltage: 6V/12V

Designed floating charge life: 12 years

Meet IEC, JIS, GB/T and YD/T testing standards

Pass UL, CE, TLC, ISO9001, ISO14001 and ISO45001 certifications

Adopt 1# electrolytic lead with a purity of up to 99.994%

Adopt special patented alloy formula, the grid has stronger corrosion resistance

Adopt high temperature and high humidity curing process, the life, capacity and batch consistency are guaranteed

The ear hanging process design has high consistency of plate curing and drying

Adopt hidden safety valve design to effectively avoid safety valve blockage

Capacity range: 33Ah-260Ah (C10, 25℃)

Rated voltage: 6V/12V

Designed floating charge life: 12 years

Meet IEC, JIS, GB/T and YD/T testing standards

Pass UL, CE, TLC, ISO9001, ISO14001 and ISO45001 certifications

Adopt 1# electrolytic lead with a purity of up to 99.994%

Adopt special patented alloy formula, the grid has stronger corrosion resistance

Adopt high temperature and high humidity curing process, the life, capacity and batch consistency are guaranteed

The ear hanging process design has high consistency of plate curing and drying

Adopt hidden safety valve design to effectively avoid safety valve blockage

Our Specifications

Specifications of RA Series Lead-Acid Batteries

Battery model	Rated voltage （V）	Rated capacity C₁₀（Ah）	Battery size				Terminal options	Terminal location
Battery model	Rated voltage （V）	Rated capacity C₁₀（Ah）	Length/mm	Width/mm	Height/mm	Total height/mm	Terminal options	Terminal location
RA6-100	6	100	194	170	205	212	F14(M8)	A
RA6-150	6	150	260	180	245	252	F12(M8)	B
RA6-180	6	180	306	168	220	227	F12(M8)	B
RA6-200	6	200	322	177.5	226	231	F16(M8) / F14(M8)	A
RA6-200S	6	200	260	180	245	252	F12(M8)	B
RA6-225	6	225	322	177.5	226	231	F16(M8) / F14(M8)	A
RA6-225S	6	225	243	187	275	275	F14(M8)	B
RA12-33	12	33	195	130	155	168	F7(M8) / F11(M6)	C
RA12-33A	12	33	195	130	155	168	F7(M8) / F11(M6)	C
RA12-35	12	35	195	130	155	168	F7(M8) / F11(M6)	C
RA12-40	12	40	198	166	169	169	F4(M5) / F11(M6)	D
RA12-45	12	45	198	166	169	169	F4(M5) / F11(M6)	D
RA12-55	12	55	229	138	211	216	F15(M6) / F11(M6)/L3	C
RA12-55A	12	55	229	138	211	216	F15(M6) / F11(M6)/L3	C
RA12-60	12	60	260	169	211	216	F11(M6)	C
RA12-65	12	65	350	167	182	182	F5(M8) / F11(M6)	C
RA12-70	12	70	350	167	182	182	F5(M8) / F11(M6)	C
RA12-70S	12	70	260	169	211	216	F15(M6) / F11(M6)/L4	C
RA12-80S	12	80	260	169	211	216	F15(M6) / F11(M6)/L4	C
RA12-80SA	12	80	260	169	211	216	F15(M6) / F11(M6)/L4	C
RA12-80	12	80	350	167	182	182	F5(M8) / F11(M6)	C
RA12-100S	12	100	306.5	168.5	210	215	F15(M6) / F12(M8)/L4	C
RA12-100SA	12	100	306.5	168.5	210	215	F15(M6) / F12(M8)/L4	C
RA12-100	12	100	328	172	215	220	F5(M8) / F12(M8)/L7	C
RA12-100A	12	100	328	172	215	220	F5(M8) / F12(M8)/L7	C
RA12-120	12	120	407	177	225	225	F5(M8) / F12(M8)	C
RA12-120A	12	120	407	177	225	225	F5(M8) / F12(M8)	C
RA12-120S	12	110	328	172	215	220	F5(M8) / F12(M8)/L7	C
RA12-120SA	12	110	328	172	215	220	F5(M8) / F12(M8)/L7	C
RA12-134	12	134	340	173	280	287	F5(M8) / F12(M8)	C
RA12-145	12	145	340	173	280	287	F5(M8) / F12(M8)	C
RA12-150	12	150	483	170	241	241	F5(M8) / F12(M8)	C
RA12-150A	12	150	483	170	241	241	F5(M8) / F12(M8)	C
RA12-160	12	160	532	207	214	219	F16(M8) / F12(M8)/L6	E
RA12-160A	12	160	532	207	214	219	F16(M8) / F12(M8)/L6	E
RA12-180	12	180	532	207	214	219	F16(M8) / F12(M8)/L6	E
RA12-180A	12	180	532	207	214	219	F16(M8) / F12(M8)/L6	E
RA12-200	12	200	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-200A	12	200	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-225	12	225	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-225A	12	225	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-230	12	230	521	269	204	209	F10(M8)/L6	E
RA12-240	12	240	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-240A	12	240	522	240	219	224	F16(M8) / F10(M8)/L6	E
RA12-260	12	260	521	268	220	225	F14(M8)/L6	E

Battery model	Rated voltage （V）	Rated capacity C₂₀（Ah）	Battery size				Terminal options	Terminal location
Battery model	Rated voltage （V）	Rated capacity C₂₀（Ah）	Length/mm	Width/mm	Height/mm	Total height/mm	Terminal options	Terminal location
RA12-38N	12	38	198	166	169	169	F4(M5) / F11(M6)	D
RA12-65N	12	65	350	167	182	182	F5(M8) / F11(M6)	C
RA12-75N	12	75	260	169	211	216	F15(M6) / F11(M6)/L4	C
RA12-100N	12	100	328	172	215	220	F5(M8) / F12(M8)/L7	C
RA12-120N	12	120	407	177	225	225	F5(M8) / F12(M8)	C
RA12-150N	12	150	483	170	241	241	F5(M8) / F12(M8)	C
