RITAR stational lead acid battery
Home >  Products >  Lead-acid Batteries >

D-KT Series

1. Capacity range: 330Ah-620Ah (C5, 25℃)

2. Rated voltage: 2V

3. Passed ISO9001, ISO14001 and ISO45001 certifications

4. Adopt 1# electrolytic lead with purity up to 99.994%

5. The positive electrode adopts a tubular plate die-cast under 10MPa pressure, with a dense grid surface and stronger corrosion resistance

Product Features

1. Capacity range: 330Ah-620Ah (C5, 25℃)

2. Rated voltage: 2V

3. Passed ISO9001, ISO14001 and ISO45001 certifications

4. Adopt 1# electrolytic lead with purity up to 99.994%

5. The positive electrode adopts a tubular plate die-cast under 10MPa pressure, with a dense grid surface and stronger corrosion resistance

6. Adopt low antimony alloy design, less water loss, and low maintenance cost

7. Adopt special explosion-proof exhaust plug with excellent air permeability, safe and reliable

8. Adopt lead cast head welded connection strip, the connection is stable and reliable

Product parameters

Battery modelRated voltage (V)Rated capacity C5(Ah)Battery sizeTerminal options
Length/mmWidth/mmHeight/mmTotal height/mm
D-330KT2330180138415460D1
D-385KT2385180138415460D1
D-440KT2440180176415460D1
D-440KT(A)2420207160330370D1
D-440KT(B)2440125158460500D1
D-560KT2560164146530580D1
D-620KT2620177160470510D1
D-560KT(A)2560125158550590D1
D350KT235093158485525D1
D450KT245093158595635D1
D500KT250093158665705D1
